TS-1000 Digital Force (Heating Units) Stirrer

Product description:

TS- Series digital magnetic (electric heating jacket) stirrer use computer chip as the main control unit, multiple digital filter circuit, PID for temperature control. High precision measurement. Two display windows.Internal and external thermocouple test temperature. Silicon controlled for output. With characteristics by fast heating, high temperature, easy operation and durable .

Features:

1、The control panel designed 30° slopes for convenient operation.

2、Available for heating and stirring standard/non-standard reaction flasks from 50 mL to 1000 mL.

3、DC brushless motor makes stable operation, low noise, long using life and no spark.

4、Metal plate shell, firm and durable, thermostability and  anti-corrosion.

5、Knob thermal control, LCD display temperature, visual intuitive and humanized design.

6、Using electric heating jacket and heating area is large,heating uniform and fast.Max surface temperature can reach 320 °C.

7、PID for temperature control. Self-tuning function.High precision measurement. Single button operation.Internal

     and external thermocouple, Silicon controlled for output. 160-240V wide voltage power supply and burnout protection function.

8、Magnetic stirring technology. Steady working at low speed, powerful working at high speed.

Parameters:

Model	TS-100	TS-250	TS-500	TS-1000
Stirring Volume	100 mL	250 mL	500 mL	1000 mL
SpeedRange	100~1800 rpm	100~1800 rpm	100~1800 rpm	100~1800 rpm
Heating Temp.	Max surface  Temp.:340 °C	Max surface  Temp.:340 °C	Max surface  Temp.:340 °C	Max surface  Temp.:340 °C
Temp. Control  Accuracy	±1 °C	±1 °C	±1 °C	±1 °C
Boiling time	1000 mL Water7~12min	1000 mL Water7~12min	1000 mL Water7~12min	1000 mL Water7~12min
Max Stirring  Volume	100 mL	250 mL	500 mL	1000 mL
Input Voltage	AC 220∨/110 V，50 Hz	AC 220∨/110 V，50 Hz	AC 220∨/110 V，50 Hz	AC 220∨/110 V，50 Hz
Motor Power	8 W	8 W	8 W	8 W
Heating Power	200 W	400 W	600 W	800 W
Fuse Protector	250 V, 2A/4A, Ф5×20	Write a review Your Name Your Review Note: HTML is not translated! Rating Rating Bad Good Continue Specifications & configuration Model 1066-1010-00 Manufacturer REACWARE Select the configuration above to check the available combination and price. CompareAdd selected configuration to enquiryOpen enquiry list ↗Print product sheet $1,186.81Choose options ↑ Custom glassware Reacware has the ability to custom fabricate glassware to your unique specifications. We specialize in custom: Chromatography Columns Flasks Manifolds Condensers Distillation apparatus Funnels Reaction Vessels and many more...... Reacware can also custom fabricate flat glass items. Borosilicate or quartz plate glass can be cut and ground to virtually any shape. Drilling, slotting or edge grinding is also offered. EXPLORE THE COLLECTION Related products More overhead stirrers. Check specifications to confirm the right fit. View category ↗ Compare 1066-1001-00 MS-40 Digital Overhead Stirrer $647.46 Add to cart ＋ Compare 1066-1002-00 Overhead Stirrer with Stirring Rod and Stand, 110 V, US Plug, Sh-II Series From $332.58 Choose options ↗ Compare 1066-1003-00 SP-200 Multi-Position Magnetic Stirrer $757.94 Add to cart ＋ Compare 1066-1004-00 SP-300 Multi-Position Magnetic Stirrer $981.29 Add to cart ＋ Compare 1066-1005-00 SP200-1 Low-Speed Magnetic Stirrer $627.26 Add to cart ＋ Compare 1066-1006-00 SP200-2T Multi-Position Hot Plate Stirrer $933.77 Add to cart ＋ Compare 1066-1007-00 TP-350 Digital Magnetic Hot Plate (Heating) $567.86 Add to cart ＋ Compare 1066-1008-00 TP-350E Digital Magnetic Stirrer Hot Plate (Heating & Stirring) $414.61 Add to cart ＋ MADE FOR YOUR APPLICATION Need custom glassware? Send us your drawings or specifications. We can help you plan the glassware for your setup. Request a custom quote ↗
