Name: Vacuum Traps, Dewar Type
Brand: REACWARE
Price: 224.53 USD
Availability: InStock

Vacuum Traps, Dewar Type

Stock: In Stock
Model: 1050-1008-00

$224.53

Available Options

Volume

Quantity

Add to Cart

Need a custom configuration? Send an enquiry

Tags: Vacuum Traps , Dewar Type

Description
Reviews

Dry ice, dewar style trap condenser designed for large volume solvent removal. Lower reservoir has a capacity of either 250, 500 or 1000 mL, with a 4 mm PTFE stopcock. Serrated hose connections are 12 mm at the smallest serration and 14 mm at the largest serration.

If you need any other size,please contact us by leaving a message.

Made from G3.3 Borosilicate Glass

Specifications & configuration

Model	1050-1008-00
Manufacturer	REACWARE
Volume options	100 mL · 250 mL · 500 mL · 1000 mL
100 mL	Inner Diameter of the Dewar X The Depth = 40 mm×60 mm
1000 mL	Inner Diameter of the Dewar X The Depth = 95 mm×330 mm
250 mL	Inner Diameter of the Dewar X The Depth = 59 mm×230 mm
500 mL	Inner Diameter of the Dewar X The Depth = 75 mm×275 mm
Material	G3.3 borosilicate glass
Annealing point	560 °C
Softening point	820 °C
Linear expansion coefficient	33 × 10⁻⁷ / °C

Select the configuration above to check the available combination and price.

Open enquiry list ↗

$224.53

Custom glassware
Specifications

Reacware has the ability to custom fabricate glassware to your unique specifications. We specialize in custom: Chromatography Columns Flasks Manifolds Condensers Distillation apparatus Funnels Reaction Vessels and many more...... Reacware can also custom fabricate flat glass items. Borosilicate or quartz plate glass can be cut and ground to virtually any shape. Drilling, slotting or edge grinding is also offered.

Volume
100 mL	Inner Diameter of the Dewar X The Depth = 40 mm×60 mm
1000 mL	Inner Diameter of the Dewar X The Depth = 95 mm×330 mm
250 mL	Inner Diameter of the Dewar X The Depth = 59 mm×230 mm
500 mL	Inner Diameter of the Dewar X The Depth = 75 mm×275 mm
