Short-Path 5 L Distillation Kit with Display Magnetic Heating Mantle

Short-Path 5 L Distillation Kit with Display Magnetic Heating Mantle
Hot
Short-Path 5 L Distillation Kit with Display Magnetic Heating Mantle
  • Stock: In Stock
  • Model: 1055-1002-00
$996.00
Add to Cart
Need a custom configuration? Send an enquiry
Tags: Short Path 5 L Distillation Kit With Display Magnetic Heating Mantle
Customization is available on request
Hand-blown
Made of borosilicate glass 3.3
Customer's Logo would be available for bulk order

Description:

This is a set of 24/40 glassware for distillation in lab. With a 14/20 joint to accept thermometers calibrated for 75 mm immersion.
The distributing adapter consists of a single 24/40 outer joint and three 24/40 inner joints to accept three 500 mL Round bottom flask receivers.
The receivers are held in place with plastic clamps. Including:

1.Distillation head, short path with 24/40 joint, with a 14/20 outer joint to accept thermometers calibrated for 75 mm immersion.one piece design for easy set up.
with removable hose connector.
2.Distributing adapter, distillation receiver, with the24/40 outer and inner joints at 135 degree angle.
with removable hose connector
3.Round Bottom flask receivers with 24/40 joint 3 pcs
4.5000 mL 2 necks flask, heavy wall design, with 24/40 joint, 1 pcs.
5.Cold Trap 24/40,100 mm outer diameter with removable hose connector,1pcs
6.1000 mL Receiving Flask,24/40,1pcs
7.thermometer adapter, 24/40 joint. 1pcs
8.thermometer adapter, 14/20 joint. 1pcs
9.Bleeding tube.2pcs.
10.Penny-Head Hollow Glass Stopper.1pcs
11.Accuracy Yellow back Thermometer.1pcs
12.110 V 50/60 Hz,450 W, Digital Magnetic Stirring 5000 mL Heating Mantle,1pcs
13.All of the clamps and stand in the picture


Made from G3.3 Borosilicate Glass

Write a review

Note: HTML is not translated!
Rating
Bad Good

Specifications & configuration

Model1055-1002-00
ManufacturerREACWARE
Material (from Product Description)G3.3 Borosilicate Glass
MaterialG3.3 borosilicate glass
Annealing point560 °C
Softening point820 °C
Linear expansion coefficient33 × 10⁻⁷ / °C
Wall constructionHeavy wall; thickness not specified
Manufacturing processHand-blown glass

Select the configuration above to check the available combination and price.

Open enquiry list ↗
$996.00
Reacware has the ability to custom fabricate glassware to your unique specifications. We specialize in custom: Chromatography Columns Flasks Manifolds Condensers Distillation apparatus Funnels Reaction Vessels and many more...... Reacware can also custom fabricate flat glass items. Borosilicate or quartz plate glass can be cut and ground to virtually any shape. Drilling, slotting or edge grinding is also offered.
