Micromanipulator MO-2 3-Dimensional with Joystick (Coarse/Fine on the Same Axis)

Micromanipulator MO-2 3-Dimensional with Joystick (Coarse/Fine on the Same Axis)
Micromanipulator MO-2 3-Dimensional with Joystick (Coarse/Fine on the Same Axis)
  • Stock: In Stock
  • Model: MO-2
  • SKU: MO-2
$2,548.26
Add to Cart
Need a custom configuration? Send an enquiry
Tags: 3 Dimensional with Joy-stick

3 Dimensional with Joy-stick (Coarse/Fine on the same axis)

You can Inject with this MO-2 only, speedy and smoothly.

・Coarse/Fine on the same axis,

　(Coarse 15 mm, Fine 5 mm)

・Absorb vibration from hands (by hydraulic fluid)

・Joy-stick allows 3 Dimensional movements

・Amazing compact and space friendly

・Remote control system

・Universally used for Right/Left handed

Included

Universal Joint　（U-1）

Travel

[Fine]X/Y/Z 5 mm ea.

500 μm one revolution handle, Scale resolution 4 μm

[Coarse]X/Y/Z 15 mm ea.　

Joy-stick on X/Y plane, 2 mm/max.

Size

[Control unit]W100mmxD180mmxH180mm

[Drive unit]W55mmxD100mmxH60mm

Weight

[Control unit]　1,220 g　[Drive unit]　230 g

Write a review

Note: HTML is not translated!
Rating
Bad Good

Specifications & configuration

ModelMO-2
ManufacturerREACWARE

Select the configuration above to check the available combination and price.
