Name: Filter Funnels, Buchner, Perforated Plates, Top Joint
Brand: REACWARE
Price: 26.01 USD
Availability: InStock

Filter Funnels, Buchner, Perforated Plates, Top Joint

Hot

Filter Funnels, Buchner, Perforated Plates, Top Joint

Stock: In Stock
Model: 1037-1002-00

$26.01

Available Options

Ground Joint

Volume

Quantity

Add to Cart

Need a custom configuration? Send an enquiry

Tags: Filter Funnels , Buchner , Perforated Plates

Description
Reviews

These funnels are especially useful where filter paper would be attacked by the material being filtered. The disc should not be subjected to pressure differential in excess of 1 atmosphere. The top edge is beaded ,With Removable Vacuum Hose

Volume	Joint	Plate OD
15	14/20	20 mm
15	19/22	20 mm
15	24/40	20 mm
30	14/20	32 mm
30	19/22	32 mm
30	24/40	32 mm
60	14/20	42 mm
60	19/22	42 mm
60	24/40	42 mm
150	19/22	60 mm
150	24/40	60 mm
150	29/42	60 mm
350	24/40	80 mm
350	29/42	80 mm
600	24/40

Specifications & configuration

Model	1037-1002-00
Manufacturer	REACWARE
Ground Joint options	14/20 · 19/22 · 24/40 · 29/42
Volume options	15 mL · 30 mL · 60 mL · 150 mL · 350 mL · 600 mL

Select the configuration above to check the available combination and price.

Open enquiry list ↗

$26.01

Custom glassware

Reacware has the ability to custom fabricate glassware to your unique specifications. We specialize in custom: Chromatography Columns Flasks Manifolds Condensers Distillation apparatus Funnels Reaction Vessels and many more...... Reacware can also custom fabricate flat glass items. Borosilicate or quartz plate glass can be cut and ground to virtually any shape. Drilling, slotting or edge grinding is also offered.
