- Stock: In Stock
- Model: 1051-1001-00
The parts in contact with the materials are
all made of high borosilicate glass (expansion coefficient 3.3) and polytetrafluoroethylene
materials, which are stable in performance and difficult to chemically react
with the materials.
The main body frame is made of cold plate
anti-corrosion spray + aluminum alloy material, and the pot is made of 304
stainless steel.
The sealing system adopts PTFE + fluorine
rubber compound combination seal.
Oil-based vacuum pressure gauge displays
real-time vacuum and pointer display.
The piston-type feeding valve is sleeved
with a polytetrafluoroethylene extension tube, which can continuously feed to
the evaporation flask under vacuum.
Vertical double-layer serpentine coil
double condenser, main cooling + secondary cooling double condenser. (EXR-1010)
Vertical serpentine coil double condenser,
two-layer coil for main cooling and three-layer coil for sub-cooling.
(EXR-1020)
Vertical three-layer serpentine coil
condenser, main cooling + sub cooling double condenser. (EXR-1050)
Large LCD screen, simultaneously controls
rotation, heating and lifting.
The rotating motor is a brushless
deceleration booster motor with no sparks and low noise. (EXR-1010, EXR-1020)
The rotating motor is a brushless
deceleration booster motor with no sparks and low noise; the lifting motor is
also a deceleration booster motor. (EXR-1050)
Bath pot thermostatic control, pot bottom
PT100 sensor + stainless steel probe.
The bath pot is electric lifted, and the
bath pot is equipped with a silicone cover, which is heat-insulating and
anti-scalding.
Rotating, heating double fuse safety
protection.
The collection bottle has a lower discharge
port and is connected with a glass + PTFE independent discharge valve.
The bottom of the pot is equipped with a
water drain valve, which is convenient for draining liquid.
The vacuum switching valve can continuously
collect and discharge materials without affecting the system vacuum and
solution distillation.
Over-temperature safety protection
function, when the actual temperature exceeds the set temperature by 5 °C, the
machine will automatically cut off the heating.
Anti-dry function, when the water level in
the heating pot is lower than the heating tube, the machine will automatically
power off.
If the machine is suddenly powered off
during work, the machine will automatically stop heating when the power is
turned on again.
The lifting motor is explosion-proof, the
LCD control meter is explosion-proof, and the cable is through the
explosion-proof tube.
Specifications & configuration
| Model | 1051-1001-00 |
|---|---|
| Manufacturer | REACWARE |
| Volume options | 50000 mL · 5000 mL · 10000 mL · 20000 mL |
Select the configuration above to check the available combination and price.
